Taramps HD 3000 Car Audio Amplifier 1 Channel 3000 Watts RMS Car Audio Amplifier 1 ohm

HD 3000 Ð 1 OHM Taramps Amplifier Module Class D (1 Channel 3.000 Watts RMS)

"With a maximum power of 3000 Watts RMS, the HD3000 is mono; 1-ohm and has 1 channel. Compatible with all types of speakers, drivers and tweeters.

* This product comes with an M1 LED Monitor

TECHNICAL INFORMATION

OPERATION CLASS Class D
NUMBER OF CHANNELS 01
MAXIMUM POWER @12.6VDC - 1 Ohm: 3000 Watts RMS
@12.6VDC - 2 Ohms: 2025 Watts RMS
@12.6VDC - 4 Ohms: 1140 Watts RMS
INPUT SENSITIVITY 230mV
SIGNAL TO NOISE RATIO 89dB
FREQUENCY RESPONSE 10Hz Hz ~ 20 kHz (-3dB)
CROSSOVER HIGH PASS (HPF) 10Hz ~ 80 Hz (-12dB/8») Variable
CROSSOVER LOW PASS (LPF) 80Hz ~ Full (-12dB/8») Variable
BASS BOOST 0 ~ 10.5dB (50 Hz)
THERMAL MANAGEMENT Smart Cooler (fan controlled by temperature or audio, with 3 speeds)
EFFICIENCY 79%
INPUT IMPEDANCE 18K ohms
OUTPUT IMPEDANCE 1 Ohm
PROTECTION SYSTEM Output Short circuit / High or Low supply voltage / Thermal protection
MIN. SUPPLY VOLTAGE 9 VDC
MAXIMUM POWER SUPPLY VOLTAGE 16 VDC
CONSUMPTION AT REST 1.8A
MAXIMUM MUSIC CONSUMPTION @12.6VDC: 150.5A
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL @12.6VDC (1kHz): 301A
DIMENSIONS (WXHXD) 9""x 2.56"" x 7.32"" (229 x 65 x 186mm)
WEIGHT 4.4lbs (2kg)
EAN 7898556840903"
